150080SS75000 Frequently Asked Questions (FAQs)

• What is the recommended land pattern for this inductor?
  The recommended land pattern for the 150080SS75000 inductor is a rectangular pad with a size of 4.5 mm x 3.2 mm, with a thermal via connecting to a larger copper area for heat dissipation.
• How do I handle the inductor's sensitivity to soldering temperature?
  To minimize the risk of damage, it is recommended to use a soldering temperature of 260°C (500°F) or lower, and to limit the soldering time to 3 seconds or less.
• What is the maximum allowed voltage for this inductor?
  The maximum allowed voltage for the 150080SS75000 inductor is 50 V, exceeding which may cause damage to the component.
• How does the inductor's core material affect its performance?
  The 150080SS75000 inductor uses a ferrite core material, which provides a high saturation point and low core losses, making it suitable for high-frequency applications.
• What is the inductor's self-resonant frequency?
  The self-resonant frequency of the 150080SS75000 inductor is approximately 100 MHz, above which the inductor's impedance starts to decrease.
