3203011 datasheet by Phoenix Contact

3203011 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector to the PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, but it's essential to consult the specific PCB design and material to ensure the correct torque value.
• Can I use this connector in high-vibration applications?
  Yes, the 3203011 connector is designed to withstand vibrations and shocks according to IEC 61373 Category 2. However, it's crucial to ensure proper mounting and screwing to the PCB to maintain the connector's integrity.
• Is the connector suitable for use in humid or wet environments?
  The 3203011 connector has a IP20 rating, which means it's protected against solid objects larger than 12 mm, but not against water or moisture. For humid or wet environments, consider using a connector with a higher IP rating or applying additional sealing measures.
• Can I use this connector with wire sizes other than AWG 20-24?
  While the datasheet specifies AWG 20-24, the connector can accommodate other wire sizes. However, it's essential to verify the wire's insulation diameter and stripping length to ensure proper connection and to avoid damage to the connector or wire.
• What is the maximum operating temperature for this connector?
  The 3203011 connector is rated for operation between -40°C to 125°C. However, it's crucial to consider the specific application and environmental conditions to ensure the connector's performance and reliability.
