90130-1126 datasheet by Molex

90130-1126 Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5-0.7 Nm (5-7 in-lbs).
• Can I use this connector in a high-vibration environment?
  Yes, the 90130-1126 is designed to withstand vibrations and can be used in applications with moderate to high vibration levels.
• Is the connector suitable for outdoor use?
  The 90130-1126 has a rating of IP67, which means it is protected against dust and can withstand immersion in water up to 1 meter for 30 minutes. However, it's recommended to use additional sealing or protective measures for extended outdoor use.
• What is the maximum operating temperature for this connector?
  The 90130-1126 has an operating temperature range of -40°C to 105°C (-40°F to 221°F).
• Can I use this connector with a different wire gauge than recommended?
  While it's technically possible to use a different wire gauge, it's not recommended as it may affect the connector's performance and reliability. The recommended wire gauge is 24-20 AWG.
