A5645H Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and design guidelines for optimal performance of the A5645H antenna?
  Antenova provides a recommended PCB layout and design guidelines in their application notes, which include keeping the antenna at least 10mm away from any metal components, using a solid ground plane, and avoiding any nearby RF-absorbing materials.
• How does the A5645H antenna perform in different environmental conditions, such as high temperature and humidity?
  The A5645H antenna is designed to operate in a wide range of environmental conditions, including temperatures from -40°C to +85°C and humidity up to 90%. However, it's recommended to consult Antenova's environmental testing reports for specific details on the antenna's performance in different conditions.
• What is the maximum power rating of the A5645H antenna, and how does it handle high-power transmissions?
  The A5645H antenna is designed to handle up to 20W of continuous power, but it's recommended to consult Antenova's application notes for specific guidelines on power handling and thermal management.
• How does the A5645H antenna perform in terms of radiation patterns and directionality?
  The A5645H antenna has a directional radiation pattern, with a peak gain of 2.5dBi. The antenna's radiation pattern is optimized for horizontal polarization, making it suitable for applications that require a directional radiation pattern.
• What is the typical lead time and MOQ for the A5645H antenna, and are there any customization options available?
  The typical lead time for the A5645H antenna is 6-8 weeks, with a minimum order quantity (MOQ) of 1000 pieces. Customization options are available, including custom cable lengths and connector types, but these may affect the lead time and MOQ.
