Broadcom recommends a 4-layer PCB with a solid ground plane, and thermal vias under the device to dissipate heat. A thermal pad on the bottom of the package should be connected to a thermal plane on the PCB.
Use a controlled impedance PCB design, keep signal traces short and away from noise sources, and use shielding or guard traces to minimize EMI emissions. Also, follow Broadcom's recommended layout guidelines.
The device requires a specific power-up sequence, with VCCIO and VCCA powered up simultaneously, followed by VCC. The power supply should ramp up slowly (e.g., 10 ms) to prevent damage.
The device has a built-in thermal shutdown feature that disables the device when it exceeds a certain temperature (typically 150°C). Ensure proper thermal design and heat dissipation to prevent overheating.
Follow the datasheet recommendations for the internal regulators and voltage references. Typically, the internal regulators require a specific voltage input and output configuration, and the voltage references require a specific load capacitance.
