A recommended PCB layout for optimal thermal performance would be to have a large copper area on the bottom layer connected to the thermal pad, and to use thermal vias to dissipate heat. A minimum of 2oz copper thickness is recommended.
To ensure the stability of the output voltage, it is recommended to use a minimum output capacitance of 10uF, and to place the output capacitor close to the output pin. Additionally, a 1uF ceramic capacitor can be added in parallel to improve high-frequency stability.
The maximum input voltage that can be applied to the device is 18V. Exceeding this voltage may cause damage to the device.
To protect the device from overcurrent, a current limiting resistor can be added in series with the input voltage. Additionally, a fuse or a PTC thermistor can be used to limit the current in case of a fault condition.
The recommended input capacitor value is 1uF to 10uF, and the recommended type is a ceramic capacitor with an X7R or X5R dielectric. This helps to filter out high-frequency noise and improve the stability of the output voltage.
