EPP-500-48 datasheet by Mean Well

EPP-500-48 Frequently Asked Questions (FAQs)

• What is the maximum operating temperature range for the EPP-500-48?
  The EPP-500-48 can operate from -20°C to 60°C, with a derating of 2.5% per degree above 40°C.
• Can I use the EPP-500-48 in a high-humidity environment?
  Yes, the EPP-500-48 is designed to operate in humid environments, with a relative humidity of up to 95% non-condensing.
• What is the hold-up time for the EPP-500-48?
  The hold-up time for the EPP-500-48 is approximately 16ms at 230Vac input and full load.
• Can I use the EPP-500-48 in a redundant configuration?
  Yes, the EPP-500-48 is designed for parallel and redundant operation, with built-in ORing diodes and current sharing.
• What is the MTBF (Mean Time Between Failures) for the EPP-500-48?
  The MTBF for the EPP-500-48 is approximately 550,000 hours at 25°C, calculated according to MIL-HDBK-217F.
