HEDS-5140#A14 datasheet by Avago Technologies

HEDS-5140#A14 Frequently Asked Questions (FAQs)

• What is the recommended operating temperature range for the HEDS-5140#A14?
  The recommended operating temperature range for the HEDS-5140#A14 is -40°C to 125°C, although it can withstand storage temperatures from -55°C to 150°C.
• How do I ensure the HEDS-5140#A14 is properly soldered to the PCB?
  To ensure proper soldering, follow the recommended soldering profile: peak temperature of 260°C, soldering time of 3 seconds, and a preheat temperature of 150°C. Also, use a solder with a melting point of 217°C to 220°C.
• What is the maximum allowable voltage for the HEDS-5140#A14?
  The maximum allowable voltage for the HEDS-5140#A14 is 5.5V, although the recommended operating voltage is 3.3V to 5V.
• How do I handle the HEDS-5140#A14 during assembly to prevent damage?
  Handle the HEDS-5140#A14 by the body, avoiding touching the leads or electrical contacts. Use an anti-static wrist strap or mat to prevent electrostatic discharge (ESD) damage.
• What is the typical response time for the HEDS-5140#A14?
  The typical response time for the HEDS-5140#A14 is 1 ms to 2 ms, although this can vary depending on the specific application and operating conditions.
