IPS161HTR Frequently Asked Questions (FAQs)

• What is the maximum operating temperature range for the IPS161HTR?
  The IPS161HTR can operate from -40°C to 150°C, making it suitable for high-reliability applications.
• How do I ensure the IPS161HTR is properly powered?
  The IPS161HTR requires a single 3.3V power supply, and it's essential to decouple the power pins with a 10uF capacitor to ensure stable operation.
• What is the maximum current rating for the IPS161HTR?
  The IPS161HTR can handle a maximum current of 1.6A per channel, making it suitable for high-current applications.
• How do I configure the IPS161HTR for half-bridge or full-bridge operation?
  The IPS161HTR can be configured for half-bridge or full-bridge operation by connecting the appropriate pins and using the enable inputs to control the high-side and low-side switches.
• What is the minimum input pulse width required for the IPS161HTR?
  The IPS161HTR requires a minimum input pulse width of 20ns to ensure proper operation.
