1.27mm Pitch SIL Vertical SMT Pin Header, 4mm mating height, gold, 20-way - see also individual drawing <a href="http://www.harwin.com/include/downloads/drawings/M52-040000P2045.PDF" title="Link to a PDF file, 94Kb">M52-040000P2045</a> (PDF, 94Kb)
The recommended torque for the M52-040000P2045 connector is 0.5 Nm to 1.5 Nm, depending on the specific application and environment.
Yes, the M52-040000P2045 connector is designed to withstand high-vibration environments, making it suitable for applications such as aerospace, defense, and industrial equipment.
Yes, the M52-040000P2045 connector is designed to operate in harsh environments, with a temperature range of -40°C to +125°C and humidity resistance up to 95% RH.
The M52-040000P2045 connector has a mating cycle life of up to 500 cycles, depending on the specific application and environment.
Yes, the M52-040000P2045 connector is designed to be compatible with automated assembly processes, including pick-and-place machines and robotic assembly systems.
M52-040000P2045 datasheet
by Harwin
