RS-75-24 datasheet by Mean Well

RS-75-24 Frequently Asked Questions (FAQs)

• What is the maximum operating temperature range for the RS-75-24?
  The RS-75-24 can operate in temperatures ranging from -20°C to 60°C, with a derating of 2.5% per degree above 40°C.
• Can the RS-75-24 be used in a high-humidity environment?
  Yes, the RS-75-24 is designed to operate in humid environments, with a relative humidity of up to 95% non-condensing.
• What is the hold-up time for the RS-75-24?
  The hold-up time for the RS-75-24 is approximately 16ms, which means the output voltage will remain stable for at least 16ms in the event of an input power failure.
• Can the RS-75-24 be used in a redundant configuration?
  Yes, the RS-75-24 can be used in a redundant configuration, but it requires an external diode or ORing circuit to prevent back-feeding between units.
• What is the MTBF (Mean Time Between Failures) for the RS-75-24?
  The MTBF for the RS-75-24 is approximately 550,000 hours, calculated according to MIL-HDBK-217F.
