The recommended footprint and land pattern for the SMBJ36CA-13-F can be found in the Diodes Incorporated's application note AN-114, which provides guidelines for PCB layout and assembly.
To ensure proper soldering and assembly, follow the recommended soldering profile and handling procedures outlined in the Diodes Incorporated's application note AN-115. Additionally, ensure that the PCB is designed with a solder mask and that the component is handled by trained personnel.
The maximum operating temperature range for the SMBJ36CA-13-F is -55°C to 150°C, as specified in the datasheet. However, it's recommended to derate the device's performance at extreme temperatures to ensure reliable operation.
Yes, the SMBJ36CA-13-F is suitable for high-reliability applications, such as aerospace, automotive, and industrial control systems. However, it's essential to follow the recommended design and assembly guidelines to ensure the device meets the required reliability standards.
To select the correct SMBJ36CA-13-F variant, consider factors such as the required breakdown voltage, peak pulse current, and package type. Consult the datasheet and application notes to determine the most suitable variant for your specific application.
SMBJ36CA-13-F datasheet
by Diodes Incorporated
