STGF20H60DF datasheet by STMicroelectronics

STGF20H60DF Frequently Asked Questions (FAQs)

• What is the maximum junction temperature that the STGF20H60DF can withstand?
  The maximum junction temperature that the STGF20H60DF can withstand is 175°C, as specified in the datasheet.
• How do I ensure the reliability of the STGF20H60DF in high-temperature applications?
  To ensure reliability in high-temperature applications, it is recommended to follow the recommended operating conditions, use a suitable thermal management system, and consider derating the device's power handling capabilities.
• What is the recommended gate resistor value for the STGF20H60DF?
  The recommended gate resistor value for the STGF20H60DF is typically in the range of 10-20 ohms, but this may vary depending on the specific application and switching frequency.
• Can I use the STGF20H60DF in a parallel configuration to increase power handling?
  Yes, the STGF20H60DF can be used in a parallel configuration to increase power handling, but it is essential to ensure that the devices are properly matched and that the gate drive and thermal management systems are designed to handle the increased power.
• What is the recommended dead-time for the STGF20H60DF in a half-bridge configuration?
  The recommended dead-time for the STGF20H60DF in a half-bridge configuration is typically in the range of 100-200 ns, but this may vary depending on the specific application and switching frequency.
